Liner DIN/Inch AWH

Reference:

Condition: New product

Liner DIN/Inch AWH

2,58 €

Quantity

Steel grade

Surface

Diameter "

Ref.	Diameter "	Steel grade	Surface	Unit price	Quantity
10024 000 100 10	1" (DN 25)	AISI 304	polished	2,58 €	Sum.:
10024 000 100 20	1" (DN 25)	AISI 304	matt	2,58 €	Sum.:
10024 000 100 40	1" (DN 25)	AISI 316	matt	3,39 €	Sum.:
10024 000 100 30	1" (DN 25)	AISI 316	polished	3,39 €	Sum.:
10024 000 112 10	1 1/2" (DN 40)	AISI 304	polished	3,14 €	Sum.:
10024 000 112 20	1 1/2" (DN 40)	AISI 304	matt	3,14 €	Sum.:
10024 000 112 40	1 1/2" (DN 40)	AISI 316	matt	4,10 €	Sum.:
10024 000 112 30	1 1/2" (DN 40)	AISI 316	polished	4,10 €	Sum.:
10024 000 200 10	2" (DN 51)	AISI 304	polished	3,73 €	Sum.:
10024 000 200 20	2" (DN 51)	AISI 304	matt	3,73 €	Sum.:
10024 000 200 40	2" (DN 51)	AISI 316	matt	4,86 €	Sum.:
10024 000 200 30	2" (DN 51)	AISI 316	polished	4,86 €	Sum.:
10024 000 212 10	2 1/2" (DN 63)	AISI 304	polished	6,10 €	Sum.:
10024 000 212 20	2 1/2" (DN 63)	AISI 304	matt	6,10 €	Sum.:
10024 000 212 40	2 1/2" (DN 63)	AISI 316	matt	8,04 €	Sum.:
10024 000 212 30	2 1/2" (DN 63)	AISI 316	polished	8,04 €	Sum.:
10024 000 300 10	3" (DN 76)	AISI 304	polished	10,61 €	Sum.:
10024 000 300 20	3" (DN 76)	AISI 304	matt	10,61 €	Sum.:
10024 000 300 40	3" (DN 76)	AISI 316	matt	14,00 €	Sum.:
10024 000 300 30	3" (DN 76)	AISI 316	polished	14,00 €	Sum.:
10024 000 400 10	4"	AISI 304	polished	14,58 €	Sum.:
10024 000 400 20	4"	AISI 304	matt	14,58 €	Sum.:
10024 000 400 40	4"	AISI 316	matt	19,00 €	Sum.:
10024 000 400 30	4"	AISI 316	polished	19,00 €	Sum.:
Total: 0,0 All prices with tax excluded.
